Base Product Number: 019276 ->, Color: Yellow, Contact Finish: Tin, Contact Material: Brass, ECCN: EAR99, Gender: Female, HTSUS: 8536.90.4000, Insulation: Fully Insulated, Insulation Diameter: 0.235 (5.97mm), Length - Overall: 1.030 (26.16mm), Moisture Sensitivity Level (MSL): 1 (Unlimited), Mounting Type: Free Hanging (In-Line), Package: Bulk, REACH Status: REACH Unaffected, RoHS Status: ROHS3 Compliant, Tab Thickness: 0.032 (0.81mm), Tab Width: 0.250 (6.35mm), Terminal Type: Standard, Termination: Crimp, Video File: Molex - Quixon Quick Disconnect Terminals, Wire Gauge: 10-12 AWG, EU RoHS: Compliant, ECCN (US): EAR99, Part Status: Active, Mounting: Cable Mount, Type: Quick Disconnect Terminal, Termination Method: Crimp, Body Orientation: Straight, Plating: Tin, Wire Size (AWG): 10-12, Maximum Voltage Rating: 600V, Minimum Operating Temperature (°C): -55, Maximum Operating Temperature (°C): 105, Packaging: Bag, Product Weight (g): 1.254, Product Length (mm): 26.1, Product Depth (mm): 9.7, Tradename: Quixon™, Бренд: Molex
