OPA2353UAThe OPA2353UA is a dual CMOS Operational Amplifier designed for miniature applications. It is optimized for low voltage, single-supply operation. Rail-to-rail input/output, low noise and high speed operation (44MHz, 22V/ms) make them ideal for driving sampling analog-to-digital converters. It is also well suited for cell phone PA control loops and video processing (75W drive capability) as well as audio and general purpose applications. Dual version has identical specifications for design flexibility. The OPA353 series operates on a single supply as low as 2.5V with an input common-mode voltage range that extends 300mV beyond the supply rails. Output voltage swing is to within 10mV of the supply rails with a 10kW load. Dual design feature completely independent circuitry for lowest crosstalk and freedom from interaction., Unity-gain stable, 5nV/?Hz Low noise, 0.0006% Low THD+noise, 5µV/°C Typical offset drift, 86dB Typical CMRR, Green product and no Sb/Br
