Brand: Hammond Item: Pushbutton consolet IP Rating: IP54 Additional Information: Purchase optional pedestal column separately Material: Carbon steel Mounting: Desktop or pedestal Color: ANSI 61 gray NEMA Rating: 12/13 Cover Type: Hinged screw cover Finish: Powder coat Keylocking: No Slope Top: No Nominal Enclosure Dimensions: 7 x 9 x 7in (HxWxD) Enclosure Height: 6.78in Enclosure Width: 8.81in Enclosure Depth: 6.94in Integral Mounting Feet: Yes Integral Mounting Flange: No Dual Access: No Knockouts: No Hinge Type: Internal lift-off hinge Number of Hinges Per Door: 2 Padlockable: No Number of Pushbutton Holes: 6 holes Pushbutton Hole Nominal Size: 30mm Hammond pushbutton consolet, 6 holes, 30mm, NEMA 12/13, 7 x 9 x 7in (HxWxD), desktop or pedestal mount, carbon steel, ANSI 61 gray, powder coat finish, hinged screw cover.
