Coil Current: 55mA, Coil Voltage: 24VDC, Contact Form: DPST-NO (2 Form A), Contact Material: Silver Copper Nickel (AgCuNi), Contact Rating (Current): 5A, ECCN: EAR99, HTSUS: 8536.49.0050, Moisture Sensitivity Level (MSL): Not Applicable, Mounting Type: DIN Rail, Operate Time: 50ms, Operating Temperature: -20В°C ~ 55В°C, Package: Bulk, Release Time: 50ms, RoHS Status: RoHS Compliant, Series: PSR ->, Switching Voltage: 250VAC, 250VDC - Max, Termination Style: Screw Terminal, EU RoHS: Compliant with Exemption, ECCN (US): EAR99, Part Status: Active, Type: Coupling Relay, Contact Arrangement: SPST-NO|SPST-NC, DC Coil Voltage (V): 24, Coil Current (mA): 55, Coil Resistance (Ohm): 436.36, Maximum Pick-Up Voltage: 20.4VDC, Maximum AC Switching Voltage (V): 250, Maximum DC Switching Voltage (V): 250, Operate Time (ms): 50, LED Indicator: No, Push to Test Button: No, Coil Suppression Diode: Yes, Relay Construction: Non-Latching, Mounting: DIN Rail, Seal: Unsealed, Minimum Operating Temperature (°C): -20, Maximum Operating Temperature (°C): 55, Product Length (mm): 22.5, Product Depth (mm): 114.5, Product Height (mm): 99, Бренд: Phoenix Contact
