Approval Agency: CSA, IEC/EN/DIN, UR, Base Product Number: ACNW3410 ->, Common Mode Transient Immunity (Min): 100kV/Вµs, Current - DC Forward (If) (Max): 25mA, Current - Output High, Low: 2.5A, 2.5A, Current - Peak Output: 3A, ECCN: EAR99, HTSUS: 8541.40.8000, Moisture Sensitivity Level (MSL): 1 (Unlimited), Mounting Type: Through Hole, Number of Channels: 1, Operating Temperature: -40В°C ~ 105В°C, Package: Tube, Package / Case: 8-DIP (0.400, 10.16mm), Propagation Delay tpLH / tpHL (Max): 150ns, 150ns, Pulse Width Distortion (Max): 80ns, REACH Status: REACH Unaffected, Rise / Fall Time (Typ): 20ns, 10ns, Supplier Device Package: 8-DIP, Technology: Optical Coupling, Voltage - Forward (Vf) (Typ): 1.45V, Voltage - Isolation: 5000Vrms, Voltage - Output Supply: 15V ~ 30V, Бренд: Broadcom Limited
