Brand: Micro Detectors Item: Proximity sensor Connection: Pigtail IP Rating: IP67 Operating Temperature: -25 to 70c Includes: Mounting hardware Housing Material: Nickel-plated brass Housing Size: 8mm diameter x 45mm body Operating Voltage: 10-30 VDC Cable Length: 6.5ft/2m Shape: Tubular Operation Mode: N.O. output Application: Standard duty Conductor Size: 26 AWG Sensor Type: Inductive Sensing Method: Extended sensing Number of Wires: 3 Switching Output: NPN Sensing Distance: 4mm Switching Frequency: 3 kHz IO-Link Compatible: No Barrel Type: Threaded Adjustable: No Mounting Type: Non-flush Weld Field Immune: No Chip Immune: No Micro Detectors inductive proximity sensor, tubular, 8mm diameter x 45mm body, nickel-plated brass housing, NPN, N.O. output, 4mm sensing distance, non-flush, 3 kHz switching frequency, IP67, pigtail.
