Length: 8мм, Глубина: 6.3мм, Clamping Voltage: 340V, Brand: Epcos, Dimensions: 8 x 6.3 x 3.2mm, Package/Case: 1210 (3225M), Capacitance: 100пФ, Thickness: 3.2мм, Maximum Surge Current: 400A, Varistor Voltage: 205V, Серия: CU, Maximum DC Voltage Rating: 170V, Maximum AC Voltage Rating: 130Vrms, Clamping Current: 5A, Capacitance @ Frequency: 100pF @ 1kHz, Current - Surge: 400A, ECCN: EAR99, Energy: 4.2J, HTSUS: 8533.40.4000, Maximum AC Volts: 130V, Maximum DC Volts: 170V, Moisture Sensitivity Level (MSL): 1 (Unlimited), Mounting Type: Surface Mount, MLCV, Number of Circuits: 1, Operating Temperature: -40В°C ~ 85В°C (TA), Package: Tape & Reel (TR)Cut Tape (CT)Digi-ReelВ®, Package / Case: 3225 (8063 Metric), REACH Status: REACH Unaffected, RoHS Status: ROHS3 Compliant, Varistor Voltage (Max): 225.5V, Varistor Voltage (Min): 184.5V, Varistor Voltage (Typ): 205V, Линейка Продукции: StandarD B726 Series, Максимальная Рабочая Температура: 85 C, Максимальное Фиксированное Напряжение: 340В, Минимальная Рабочая Температура: -40 C, Номинальное Напряжение AC: 130В, Номинальное Напряжение DC: 170В, Пиковый Импульсный Ток при 8/20мкс: 400А, Стиль Корпуса Варистора: 3225 [8063 Metric], Тип Варистора: Металлооксидный Варистор (MOV), Automotive: Yes, Capacitance Value: 100pF, Clamping Current (A): 5, Clamping Voltage (V): 340, ECCN (US): EAR99, Energy (J): 4.2, EU RoHS: Compliant, Lead Style: J-Lead, Maximum AC Voltage Rating (V): 130, Maximum DC Voltage Rating (V): 170, Maximum Operating Temperature (°C): 85, Maximum Surge Current (A): 400, Minimum Operating Temperature (°C): -40, Mounting: Surface Mount, Packaging: Tape and Reel, Part Status: Active, PPAP: Unknown, Size Code: 3225, Technology: Multilayer, Tolerance Voltage: 10%, Varistor Voltage (V): 205, Вес, г: 0.87, Бренд: EPCOS
