Length: 8mm, Depth: 6.3mm, Clamping Voltage: 650V, Brand: Epcos, Dimensions: 8 x 6.3 x 4.5mm, Package/Case: 1210 (3225M), Capacitance: 55pF, Thickness: 4.5mm, Maximum Surge Current: 400A, Varistor Voltage: 390V, Series: CU, Maximum DC Voltage Rating: 320V, Maximum AC Voltage Rating: 250Vrms, Clamping Current: 5A, EU RoHS: Compliant, ECCN (US): EAR99, Part Status: Active, Mounting: Surface Mount, Technology: Multilayer, Varistor Voltage (V): 390, Maximum AC Voltage Rating (V): 250, Maximum DC Voltage Rating (V): 320, Clamping Voltage (V): 650, Tolerance Voltage: 10%, Clamping Current (A): 5, Maximum Surge Current (A): 400, Capacitance Value: 55pF, Energy (J): 8.2, Minimum Operating Temperature (°C): -40, Maximum Operating Temperature (°C): 85, Size Code: 3225, Packaging: Tape and Reel, Product Length (mm): 8, Product Depth (mm): 6.3, Product Height (mm): 4.5, Lead Style: J-Lead, Allowable Voltage(Vdc): 320V, Peak Surge Current: 400A, Varistor Voltage(Max): 429V, Вес, г: 1, Бренд: EPCOS
