Brand: NITRA Item: EtherNet/IP protocol modular plate IP Rating: IP65 For Use With: CMV series solenoid valves Requires: 4-pin M8 power cable Body Material: Anodized aluminum Electrical Connection: (2) 5-pin M12 and (1) 4-pin M8 quick-disconnect Working Fluid: Air or inert gas Flow Coefficient: 12.4 Inlet Port: (2) 3/8in push-to-connect Exhaust Port: 3/8in female NPT Pilot Port: 5/32in (4mm) push-to-connect Pneumatic Function: Left supply/exhaust end NITRA pneumatic EtherNet/IP protocol modular plate, left supply/exhaust end, Cv=12.4, (2) 3/8in push-to-connect inlet(s), 3/8in female NPT exhaust(s), 5/32in (4mm) push-to-connect pilot(s), anodized aluminum body, IP65.
