Actuator Type: Lever, Formed, Circuit: SPDT, Current Rating (Amps): 11A (AC), 6A (DC), Differential Travel: 0.047 (1.2mm), ECCN: EAR99, Electrical Life: 200,000 Cycles, HTSUS: 8536.50.9040, Ingress Protection: IP40, Mechanical Life: 10,000,000 Cycles, Moisture Sensitivity Level (MSL): 1 (Unlimited), Mounting Type: Chassis Mount, Operating Force: 150gf, Operating Position: 0.798 (20.3mm), Operating Temperature: -25В°C ~ 105В°C, Overtravel: 0.055 (1.4mm), Package: Bulk, Pretravel: 0.134 (3.4mm), Release Force: 20gf, RoHS Status: RoHS Compliant, Series: D3V ->, Switch Function: On-Mom, Termination Style: Quick Connect - 0.187 (4.7mm), Voltage Rating - AC: 250V, Voltage Rating - DC: 30V, EU RoHS: Compliant, ECCN (US): EAR99, Part Status: Unconfirmed, HTS: 8536.50.90.40, Switch Configuration: N.O./N.C., Actuator Style: Long Hinge Lever, Pole Throw Configuration: SPDT, Maximum Current Rating (A): 11@250VAC, Maximum Power Rating (VA): 372.85@(CSA/UL), Electrical Life (Cycles): 200000, Mechanical Life (Cycles): 10000000, Maximum Movement Differential (mm): 2, Mounting: Screw Mount, Body Orientation: Straight, Minimum Operating Temperature (°C): -25, Maximum Operating Temperature (°C): 105, Body Length (mm): 29.4, Body Depth (mm): 10.3, Body Height (mm): 15.9, Operating Force (N): 0.69, Клеммы Переключателя: Quick Connect, Конфигурация Контакта: SPDT, Максимальная Рабочая Сила: 200гс, Максимальный Ток Контакта: 11А, Механизм Микропереключателя: Long Hinge Lever, Номинальное Напряжение Контакта AC: 250В AC, Номинальное Напряжение Контакта DC: 250В DC, Тип Микропереключателя: Miniature, Бренд: Omron
