Brand: Endress+Hauser Item: Flow meter IP Rating: IP65 and IP67 Series: Picomag Port Protocol(s): IO-Link Class A Device Output: Switch, pulse, analog or discrete input, PNP/NPN selectable or 4-20 mA/2-10 VDC, IO-Link Operating Voltage: 18-30 VDC Additional Information: Purchase cable separately Communication Port and Connection Type(s): (1) 4-pin M12 A-coded (IO-Link)Bluetooth Port Speed(s): IO-Link COM2BLE 802.15.1 IO-Link Version: IO-Link v1.1 Standard I/O Mode Supported: Yes Media Type: Water, potable water and chemicals Requires: An Android or iOS device with Bluetooth connectivity and SmartBlue App (free download from the Google Play Store and Apple App Store) is required for full sensor configuration. Electrical Connection: 4-pin M12 quick-disconnect Output 2: Switch, analog or discrete input, PNP/NPN selectable or 4-20 mA/2-10 VDC Process Connection: 2in female NPT Wetted Parts: 316 stainless steel, PEEK, FKM Seal Material: FKM Sensing Type: Magnetic-inductive Measuring Range: 0 to 198.1 GPM Volume Flow Rate Units: GPM, fl oz/min, l/min, l/sec, l/hr, m3/hr, selectable Measuring Range 2: 14 to 158 deg F Temperature Units: F, C, selectable Measuring Range 3: +/- 3.436E10 liters Volume Flow Totalizer Units: Gal, kgal, fl oz, l, kl, Ml, m3, selectable Measuring Range 4: 20 to 10,000 µS/cm Conductivity Units: S/m, mS/cm, µS/cm, selectable Endress+Hauser Picomag liquid flow meter, magnetic-inductive, 2in female NPT, 0 to 198.1 GPM, 14 to 158 deg F, +/- 3.436E10 liters, 20 to 10,000 µS/cm, Output: switch, pulse, analog, discrete input, IO-Link, Output 2: switch, analog, discrete input, FKM seal(s).
