Brand: Contrinex Item: Proximity sensor Connection: Pigtail IP Rating: IP67 Operating Temperature: -25 to 70 deg C Includes: Mounting hardware Port Protocol(s): IO-Link Class A Device Housing Material: Polycarbonate Housing Size: 12 x 27 x 6.5mm body Operating Voltage: 10-30 VDC Cable Length: 6.5ft/2m Shape: Rectangular Communication Port and Connection Type(s): (1) 3-wire pigtail (IO-Link) port(s) Port Speed(s): IO-Link COM2 IO-Link Version: IO-Link v1.0 Standard I/O Mode Supported: Yes Jacket Material: Carbon steel Operation Mode: N.O. output Application: Standard duty, small space and IO-Link Conductor Size: 26 AWG Sensor Type: Inductive Sensing Method: Standard sensing Number of Wires: 3 Switching Output: PNP Sensing Distance: 4mm Switching Frequency: 2000 Hz IO-Link Compatible: Yes Adjustable: No Mounting Type: Non-flush Weld Field Immune: No Chip Immune: No Sensing Face: Top sensing Contrinex inductive proximity sensor, rectangular, 12 x 27 x 6.5mm body, polycarbonate housing, top sensing, PNP, N.O. output, 4mm sensing distance, non-flush, 2000 Hz switching frequency, IP67, pigtail.
