Brand: Contrinex Item: Proximity sensor Connection: Pigtail IP Rating: IP67 Operating Temperature: -25 to 70c Includes: Mounting hardware Port Protocol(s): IO-Link Class A Device Housing Material: 304 stainless steel Housing Size: 8mm diameter x 22mm body Operating Voltage: 10-30 VDC Cable Length: 6.5ft/2m Shape: Tubular Communication Port and Connection Type(s): (1) 3-wire pigtail (IO-Link) port(s) Port Speed(s): IO-Link COM2 IO-Link Version: IO-Link v1.0 Standard I/O Mode Supported: Yes Jacket Material: PVC Operation Mode: N.O. output Application: Standard duty and IO-Link Conductor Size: 26 AWG Sensor Type: Inductive Sensing Method: Standard sensing Number of Wires: 3 Switching Output: PNP Sensing Distance: 2.5mm Switching Frequency: 4.5 kHz IO-Link Compatible: Yes Barrel Type: Threaded Adjustable: No Mounting Type: Non-flush Weld Field Immune: No Chip Immune: No Contrinex inductive proximity sensor, tubular, 8mm diameter x 22mm body, 304 stainless steel housing, PNP, N.O. output, 2.5mm sensing distance, non-flush, 4.5 kHz switching frequency, IP67, pigtail.
