Brand: Contrinex Item: Proximity sensor Connection: 4-pin M12 quick-disconnect IP Rating: IP68 Operating Temperature: -25 to 100 deg C Includes: Mounting hardware Port Protocol(s): IO-Link Class A Device Housing Material: 304 stainless steel Housing Size: 12mm diameter x 56mm body Operating Voltage: 10-30 VDC Additional Information: Purchase cable separately Shape: Tubular Communication Port and Connection Type(s): (1) 4-pin M12 A-coded (IO-Link) port(s) Port Speed(s): IO-Link COM2 IO-Link Version: IO-Link v1.1 Standard I/O Mode Supported: Yes Operation Mode: N.O. Application: High pressure hydraulic and IO-Link Sensor Type: Inductive Sensing Method: Standard sensing Number of Wires: 3 Switching Output: PNP Sensing Distance: 1.5mm Switching Frequency: 600 Hz IO-Link Compatible: Yes Barrel Type: Threaded Adjustable: No Mounting Type: Flush Weld Field Immune: No Chip Immune: No Operating Pressure: 7252psi (500 bar) Contrinex inductive proximity sensor, tubular, 12mm diameter x 56mm body, 304 stainless steel housing, PNP, N.O., 1.5mm sensing distance, flush, 600 Hz switching frequency, IP68, 4-pin M12 quick-disconnect.
