Brand: Marathon Item: Motor IP Rating: IP22 Mounting: C-face/rigid base Manufacturer Part Number: 056B17DRR70008A1 Voltage Rating: 100-120/200-240 VAC Horsepower Rating: 3/4hp Shaft Type: Round with square key Enclosure Type: ODP Voltage Type: AC Number of Phases: 1 Frame Material: Rolled steel Nameplate RPM: 1725rpm Motor Frame: NEMA 56C Motor Type: Induction Integrated Brake: No Shaft Diameter: 5/8in Efficiency: 81.8 Overload Type: Manual Efficiency Group: Premium efficiency Motor Application: General purpose Synchronous Speed: 1800rpm Shaft Material: AISI 1215 (MS1000) steel Electrically Reversible: Yes Insulation Class: Class B Service Factor: 1.25 NEMA Design: Design N Junction Box Orientation: F1 Mounting Orientation: Horizontal Marathon premium efficiency AC induction motor, general purpose, 3/4hp, 1-phase, 100-120/200-240 VAC, 1800rpm, ODP, NEMA 56C frame, rolled steel, C-face/rigid base mount.
