Brand: NITRA Item: Valve For Use With: Pneumatic pushbutton operators Body Material: Aluminum Number Of Positions: 2 Operator Type: Metal plunger Action: Spring return Working Fluid: Air Valve Type: Manual directional control Port Quantity: 2-port (3-way) Valve Configuration: N.O. Stackable: No Maximum Operating Pressure: 145 psi (10 bar) Flow Coefficient: 0.13 Minimum Operating Pressure: 7 psi (0.5 bar) Inlet Port: (1) 5/32in (4mm) push-to-connect Outlet Port: (1) 5/32in (4mm) push-to-connect Exhaust Port: (1) vent hole Port Orientation: Axial NITRA pneumatic manual valve, 2-port (3-way), 2-position, N.O., metal plunger, spring return, axial ports, (1) 5/32in (4mm) push-to-connect inlet(s), (1) 5/32in (4mm) push-to-connect outlet(s), (1) vent hole exhaust(s), Cv=0.13.
