Coil Voltage: 12V dc, Isolation Coil To Contact: 3kV ac, Length: 20mm, Maximum Switching Power DC: 150 W, Brand: Omron, Series: G6B, Mounting Type: PCB Mount, Coil Power: 200mW, Coil Resistance: 720 ?, Terminal Type: Through Hole, Contact Configuration: SPDT, Height: 11mm, Switching Current: 5A, Maximum Switching Power AC: 1.25 kVA, Depth: 11mm, Maximum Switching Voltage AC: 380V, Maximum Switching Voltage DC: 125V, EU RoHS: Compliant, ECCN (US): EAR99, Part Status: Active, HTS: 8536.41.00.60, Contact Arrangement: SPST-NO|SPST-NC, Contact Form: 1 Form B|1 Form A, DC Coil Voltage (V): 12, Coil Current (mA): 16.7, Coil Resistance (Ohm): 720, Maximum Pick-Up Voltage: 8.4VDC, Minimum Dropout Voltage: 1.2VDC, Maximum AC Switching Voltage (V): 250, Maximum DC Switching Voltage (V): 30, Maximum Switching Current (A): 5, Operate Time (ms): 10, Release Time (ms): 10, LED Indicator: No, Push to Test Button: No, Coil Suppression Diode: No, Relay Construction: Non-Latching, Mounting: Through Hole, Termination Style: PC Pin, Number of Terminals: 6, Minimum Operating Temperature (°C): -25, Maximum Operating Temperature (°C): 70, Product Weight (g): 3.5 to 4.6, Product Length (mm): 20, Product Depth (mm): 11, Product Height (mm): 11, Бренд: Omron
