Brand: DURApulse Item: Drive IP Rating: IP20 Series: GS30 Port Protocol(s): Modbus RTU SlaveModbus ASCII Slave Additional Information: Optional communication, encoder and I/O modules available For Use With: 3-phase induction and permanent magnet AC motors Mounting: Panel or wall Communication Port and Connection Type(s): (1) RS-485 (RJ45)(1) USB B Port Speed(s): up to 115.2k baud Connector Type: Spring clamp terminals Amperage Rating: 33A Load Current: 3A/point relay, 50 mA/point discrete Frame Size: E Fuse Type: User-supplied external fuse Discrete Input Type: Sinking/sourcing Discrete Output Type: Relay/sinking/sourcing Number of Analog Input Channels: 2 Analog Input Signal Type: Current/voltage Input Resolution: 12-bit Input Current Signal Range: 0-20 mA and 4-20 mA Input Voltage Signal Range: +/- 10 VDC Relay Configuration: (1) Form C (SPDT) relay Enclosure Type: Enclosed Controller Type: High-performance Voltage Type: AC Nominal Drive Input Voltage: 230 VAC Nominal Drive Output Voltage: 230 VAC Number of Input Phases: 3 Number of Output Phases: 3 Horsepower By Input Phase: 10hp with 3-phase input Variable Torque Amperage Rating: 36A Control Mode: SVC, V/Hz, FOC, encoder or torque Integrated EMI Filter: No Safe Torque Off (STO): Yes Temperature Rating: -20 to 50 deg C Dynamic Braking: Integrated dynamic braking Input Signal: 4-20 mA, voltage, potentiometer or pulse train input Output Type: PWM output Reverse Capability: Built-in Internally Bypassed: No Carrier Frequency Range: 2-15 kHz Output Frequency Range: 0.1-599 Hz Number Of Input Channels: 2 Number of Non-Isolated Analog Input Commons: 1 Number of Points per Analog Input Common: 2 Number of Analog Output Channels: 1 Number Of Output Channels: 1 Analog Output Signal Type: Current/voltage Number of Non-Isolated Analog Output Commons: 1 Number of Points per Analog Output Common: 1 Output Resolution: 10-bit Output Voltage Signal Range: 0-10 VDC Number of Discrete Input Points: 7 Nominal Discrete Input Voltage: 24 VDC Number of Non-Isolated Discrete Input Commons: 2 Number of Points per Discrete Input Common: 4 Number of Discrete Output Points: 3 Nominal Discrete Output Voltage: 240 VAC and 30 VDC Number of Non-Isolated Discrete Output Commons: 1 Number of Isolated Discrete Output Commons: 1 Number of Points per Discrete Output Common: 2 Programming Language: Ladder Output Current Signal Range: 0-20 mA and 4-20 mA DURApulse GS30 series AC high-performance drive, enclosed, 230 VAC, 10hp with 3-phase input, SVC, V/Hz, FOC, encoder or torque mode, E frame, RS-485, integrated dynamic braking. Optional communication, encoder and I/O modules available.
