Brand: Contrinex Item: Proximity sensor Connection: 4-pin M12 quick-disconnect IP Rating: IP67 Operating Temperature: -25 to 70 deg C Includes: Mounting hardware Port Protocol(s): IO-Link Class A Device Housing Material: Chrome-plated brass Housing Size: 12mm diameter x 60mm body Operating Voltage: 10-30 VDC Additional Information: Purchase cable separately Shape: Tubular Communication Port and Connection Type(s): (1) 4-pin M12 A-coded (IO-Link) port(s) Port Speed(s): IO-Link COM2 IO-Link Version: IO-Link v1.1.2 (compatible with v1.1.3) Standard I/O Mode Supported: Yes Operation Mode: N.O. output Application: Standard duty, IO-Link, smart output and measurement Sensor Type: Inductive Sensing Method: Triple sensing Number of Wires: 4 Switching Output: PNP Sensing Distance: 6mm Switching Frequency: 125 Hz IO-Link Compatible: Yes Barrel Type: Threaded Adjustable: Yes Mounting Type: Semi-flush Weld Field Immune: No Chip Immune: No Contrinex inductive proximity sensor, tubular, 12mm diameter x 60mm body, chrome-plated brass housing, PNP, N.O. output, 6mm sensing distance, semi-flush, 125 Hz switching frequency, IP67, 4-pin M12 quick-disconnect.
