Length: 3.2mm, Shielded: Yes, Depth: 2.5mm, Brand: Murata, Dimensions: 3.2 x 2.5 x 1.55mm, Inductor Construction: Wire-Wound, Package/Case: 1210 (3225M), Maximum Operating Temperature: +85°C, Maximum DC Resistance: 91.2m?, Maximum dc Current: 1.6A, Minimum Operating Temperature: -40°C, Series: LQH32P, Height: 1.55mm, Core Material: Ferrite, Maximum Self Resonant Frequency: 70MHz, Tolerance: ±30%, Inductance: 2.2 ?H, Base Product Number: LQH32PN ->, Current - Saturation (Isat): 1.55A, Current Rating (Amps): 1.6A, DC Resistance (DCR): 91.2mOhm Max, ECCN: EAR99, Frequency - Self Resonant: 70MHz, Height - Seated (Max): 0.067 (1.70mm), HTSUS: 8504.50.4000, Inductance Frequency - Test: 1MHz, Material - Core: Ferrite, Moisture Sensitivity Level (MSL): 1 (Unlimited), Mounting Type: Surface Mount, Operating Temperature: -40В°C ~ 85В°C, Package: Tape & Reel (TR)Cut Tape (CT)Digi-ReelВ®, Package / Case: Nonstandard, RoHS Status: ROHS3 Compliant, Shielding: Shielded, Size / Dimension: 0.126 L x 0.098 W (3.20mm x 2.50mm), Supplier Device Package: 1210 (3225 Metric), Type: Wirewound, Вес, г: 0.073, Бренд: Murata Electronics
