Brand: Contrinex Item: Photoelectric sensor Connection: 4-pin M12 quick-disconnect IP Rating: IP67 Includes: Mounting hardware Port Protocol(s): IO-Link Class A Device Light Emission: Visible red Housing Material: ABS plastic Housing Size: 18mm diameter x 27mm body Operating Voltage: 10-30 VDC Additional Information: Purchase cable separately Shape: Tubular Communication Port and Connection Type(s): (1) 4-pin M12 A-coded (IO-Link) port(s) Port Speed(s): IO-Link COM2 IO-Link Version: IO-Link v1.0 Standard I/O Mode Supported: Yes Operation Mode: Complementary light-on/dark-on Application: Standard duty and IO-Link Sensing Method: Diffuse Number of Wires: 4 Switching Output: PNP Sensing Distance: 3-1200mm Sensitivity: Potentiometer Switching Frequency: 1.5 kHz IO-Link Compatible: Yes Barrel Type: Threaded Contrinex photoelectric sensor, tubular, threaded, diffuse, visible red, 3-1200mm sensing distance, complementary light-on/dark-on, PNP, potentiometer, 1.5 kHz switching frequency, ABS plastic housing, 4-pin M12 quick-disconnect.
