EU RoHS: Compliant, ECCN (US): EAR99, Part Status: Active, Lead Shape: Through Hole, PCB changed: 14, Package Length: 19.05, Package Width: 6.35, Package Height: 3.3, Mounting: Through Hole, Type: Low Power Amplifier, Manufacturer Type: Low Power Amplifier, Number of Channels per Chip: 4, Rail to Rail: Rail to Rail Input/Output, Process Technology: CMOS, Output Type: CMOS, Maximum Input Offset Voltage (mV): 4.5@5.5V, Minimum Single Supply Voltage (V): 1.8, Typical Single Supply Voltage (V): 3|5, Maximum Single Supply Voltage (V): 6, Maximum Input Offset Current (uA): 0.000001(Typ)@5.5V, Typical Input Bias Current (uA): 0.000001@5.5V, Maximum Quiescent Current (mA): 0.68@5.5V, Typical Output Current (mA): 30(Max), Power Supply Type: Single, Typical Slew Rate (V/us): 0.6@5.5V, Typical Input Noise Voltage Density (nV/rtHz): 28@5.5V, Input Offset Voltage Drift (uV/°C): 2(Typ), Typical Voltage Gain (dB): 112, Typical Noninverting Input Current Noise Density (pA/rtHz): 0.0006@5.5V, Minimum PSRR (dB): 86(Typ), Minimum CMRR (dB): 60, Minimum CMRR Range (dB): 60 to 65, Typical Gain Bandwidth Product (MHz): 1, Shut Down Support: No, Minimum Operating Temperature (°C): -40, Maximum Operating Temperature (°C): 125, Supplier Temperature Grade: Extended, Packaging: Tube, Pin Count: 14, Standard Package Name: DIP, Supplier Package: PDIP, Вес, г: 4.763, Бренд: Microchip Technology
