Brand: Optris Item: Pyrometer IP Rating: IP65 Operating Temperature: -20 to 85 deg C Series: CSmicro 3M Output: 0-5 VDC, 0-10 VDC, alarm or pulse Response Time: 8ms Operating Voltage: 5-30 VDC Mounting: M12x1 threaded end Media Type: Liquid, water, oil, chemicals and bulk solids Requires: An Optris ACCSMIACC configuration cable and Optris PC or Android software (free download from the AutomationDirect Web site or Google Play) for sensor configuration Application: Low-temperature metallic surfaces and measurement through glass Sensor Type: Infrared NEMA Rating: 4 Electrical Connection: 6m integral 5-conductor shielded cable Temperature Sensing Range: 50 to 350 deg C Spectral Range: 2.3 µm Distance To Spot Size Ratio: 22:1 (50mm @ 1100mm) Optris CSmicro 3M infrared pyrometer, 50 to 350 deg C, 2.3 µm spectral range, 0-5 VDC, 0-10 VDC, alarm or pulse output, 5-30 VDC operating voltage, M12x1 threaded end mount, 6m integral 5-conductor shielded cable.
