Current - Collector (Ic) (Max): 20mA, Current - Dark (Id) (Max): 100nA, ECCN: EAR99, HTSUS: 8541.40.7080, Moisture Sensitivity Level (MSL): 1 (Unlimited), Mounting Type: Through Hole, Operating Temperature: -25В°C ~ 85В°C (TA), Orientation: Top View, Package: Bulk, Package / Case: Radial, 5mm Dia (T 1 3/4), RoHS Status: ROHS3 Compliant, Voltage - Collector Emitter Breakdown (Max): 30V, Wavelength: 940nm, EU RoHS: Compliant, ECCN (US): EAR99, Part Status: Active, HTS: 8541.40.20.00, Type: Chip, Phototransistor Type: Phototransistor, Lens Shape Type: Domed, Lens Color: Black, Material: Silicon, Number of Channels per Chip: 1, Polarity: NPN, Viewing Orientation: Top View, Peak Wavelength (nm): 940, Maximum Rise Time (ns): 15000(Typ), Maximum Fall Time (ns): 15000(Typ), Maximum Collector Current (mA): 20, Maximum Dark Current (nA): 100, Maximum Emitter-Collector Voltage (V): 5, Maximum Collector-Emitter Voltage (V): 30, Maximum Collector-Emitter Saturation Voltage (V): 0.4, Maximum Power Dissipation (mW): 75, Fabrication Technology: NPN Transistor, Minimum Operating Temperature (°C): -25, Maximum Operating Temperature (°C): 85, Packaging: Bag, Standard Package Name: T-1, Supplier Package: T-1, Pin Count: 2, Diameter: 5.9, Mounting: Through Hole, Package Height: 8.6, PCB changed: 2, Lead Shape: Through Hole, Бренд: Everlight Electronics
