Brand: Endress+Hauser Item: Digital pressure sensor Series: Ceraphant Port Protocol(s): IO-Link Class A Device Output: 4-20 mA Operating Voltage: 18-30 VDC Additional Information: Purchase cable separately Communication Port and Connection Type(s): (1) 4-pin M12 A-coded (IO-Link) port(s) Port Speed(s): IO-Link COM2 IO-Link Version: IO-Link v1.1 Media Type: Liquid and gases Electrical Connection: 4-pin M12 quick-disconnect Output 2: Switch PNP, N.O./N.C. selectable or IO-Link Display Type: 4-digit, LCD display Process Connection: 1-1/2in sanitary tri-clamp Pressure Range: 0 to 15 psig Endress+Hauser Ceraphant digital pressure sensor, 0 to 15 psig range, Output: 4-20 mA, Output 2: switch PNP, N.O./N.C. selectable or IO-Link, 1-1/2in sanitary tri-clamp process connection.
