Brand: GC Valves Item: Valve Operating Voltage: 120 VAC Body Material: Brass Power Rating: 8 VA Number Of Positions: 2 Electrical Connection: 18mm DIN style wiring plug Seal Material: Viton Action: Single solenoid spring return Working Fluid: Pneumatic, inert gas, water, coolant or light oil Valve Type: Solenoid process Port Quantity: 2-port (2-way) Valve Configuration: N.C. Maximum Operating Pressure: Varies with fluid Flow Coefficient: 6.1 Minimum Operating Pressure: 1 psi Inlet Port: 3/4in female NPT Outlet Port: 3/4in female NPT Working Fluid Temperature: 230 deg F maximum GC Valves solenoid valve, 2-port (2-way), 2-position, N.C., brass body, Viton seal(s), 3/4in female NPT inlet(s), 3/4in female NPT outlet(s), Cv=6.1, 1 psi minimum operating pressure, 120 VAC operating voltage, 18mm DIN style wiring plug.
