Brand: Saginaw Item: HMI Enclosure IP Rating: IP66 Additional Information: Max front cut-out area 17.5 x 21.5in Material: 304 stainless steel Mounting: Suspension or pedestal NEMA Rating: 3R/4/4X/12/13 Cover Type: Screw cover front, single door rear Finish: #4 brush Keylocking: No Slope Top: No 3-Piece Assembly: No Vented: No Nominal Enclosure Dimensions: 20 x 24 x 10in (HxWxD) Dual Access: Yes Knockouts: No Hinge Type: Concealed hinges Number of Hinges Per Door: 2 Latch Type: 1/4-turn semi-flush latch Padlockable: No Number Of Latches: 1 Saginaw HMI Enclosure, NEMA 3R/4/4X/12/13, 20 x 24 x 10in (HxWxD), suspension or pedestal mount, dual access, 304 stainless steel, #4 brush finish, screw cover front, single door rear, 1/4-turn semi-flush latch.
