Brand: Saginaw Item: Enclosure IP Rating: IP32 Material: Carbon steel Mounting: Wall Color: ANSI 61 gray NEMA Rating: 3R Cover Type: Single-door Finish: Powder coat Keylocking: No Subpanel: Purchase subpanel separately Slope Top: No 3-Piece Assembly: No Vented: No Nominal Enclosure Dimensions: 36 x 24 x 8in (HxWxD) Enclosure Height: 36.00in Enclosure Width: 24.20in Enclosure Depth: 9.70in Integral Mounting Feet: No Integral Mounting Flange: No Dual Access: No Knockouts: No Bottom Gland Plate: No Hinge Type: Concealed hinges Number of Hinges Per Door: 2 Latch Type: 1/4-turn padlocking wing handle Shelf: No Padlockable: Yes Number Of Latches: 1 Secondary Latch Type: 1/4-turn semi-flush Number Of Secondary Latches: 1 Saginaw enclosure, NEMA 3R, 36 x 24 x 8in (HxWxD), wall mount, carbon steel, ANSI 61 gray, powder coat finish, single-door, 1/4-turn padlocking wing handle.
