Actuator Type: Round (Pin Plunger), Circuit: SPDT, Current Rating (Amps): 3A (AC/DC), Differential Travel: 0.006 (0.15mm), ECCN: EAR99, Electrical Life: 100,000 Cycles, HTSUS: 8536.50.9040, Ingress Protection: IP40, Mechanical Life: 1,000,000 Cycles, Moisture Sensitivity Level (MSL): Not Applicable, Mounting Type: Chassis Mount, Operating Force: 153gf, Operating Position: 0.330 (8.4mm), Operating Temperature: -25В°C ~ 85В°C, Overtravel: 0.015 (0.4mm), Package: Tray, Pretravel: 0.024 (0.6mm), Release Force: 20gf, RoHS Status: RoHS Compliant, Series: SS-P ->, Switch Function: On-Mom, Termination Style: Solder Lug, Voltage Rating - AC: 125V, Voltage Rating - DC: 30V, Бренд: Omron
