Brand: Dold Item: Soft starter IP Rating: IP20 Series: MINISTART 9019 Mounting: 35mm DIN rail Amperage Rating: 9A Protection Type(s): over-temperature Frame Size: 22mm SCCR Rating: 5kA SCCR Nominal Input Voltage: 208 VAC/220-240 VAC/440-480 VAC Nominal Output Voltage: 208 VAC/220-240 VAC/440-480 VAC Enclosure Type: Enclosed Controller Type: Compact Number of Input Phases: 3 Number of Output Phases: 3 Control Mode: Sinusoidal Temperature Rating: 0 to 60 deg C Output Type: SCR output Reverse Capability: None Internally Bypassed: Yes Output Frequency Range: 50-60 Hz Starts per Hour: 30 Number of Controlled Output Phases: 2 Control Power Requirement: 24 VDC Derating: Derating required for temperatures above 40 deg C see specifications for appropriate derating Mains Isolating Relay: No Dold MINISTART 9019 series compact soft starter, 9A, 200-480 VAC at 3-phase, rated for 30 start/hour, internally bypassed, 22mm frame.
