Brand: Marathon Item: Motor IP Rating: IP43 Includes: Dynapar HS20 encoder Series: MAX Plus Mounting: C-face/removable rigid base Manufacturer Part Number: 145THTN17034 Voltage Rating: 230/460 VAC Horsepower Rating: 2hp Shaft Type: Round with square key Enclosure Type: TENV Voltage Type: AC Number of Phases: 3 Frame Material: Cast iron Nameplate RPM: 1750rpm Motor Frame: NEMA 145C Motor Type: Induction Integrated Brake: No Shaft Diameter: 7/8in Efficiency: 85.5 Overload Type: None Efficiency Group: High efficiency Motor Application: High-performance inverter duty Synchronous Speed: 1800rpm Shaft Material: 1144 Stressproof (C-223) steel Electrically Reversible: Yes Insulation Class: Class F Service Factor: 1.0 NEMA Design: Design B Junction Box Orientation: F1 reversible Mounting Orientation: Horizontal Constant Torque Rating: 1000:1 Variable Torque Rating: 10:1 Marathon MAX Plus high efficiency AC induction motor, high-performance inverter duty, 2hp, 3-phase, 230/460 VAC, 1800rpm, TENV, NEMA 145C frame, cast iron, C-face/removable rigid base mount. Dynapar HS20 encoder included.
