EU RoHS: Compliant, ECCN (US): EAR99, Part Status: Active, HTS: 8536.69.40.40, Type: Power, Gender: HDR, Number of Contacts: 8, Number of Terminals: 8, Number of Ports: 1, Termination Method: Solder, Terminal Pitch (mm): 3, Body Orientation: Straight, Maximum Current Rating (A): 8.5/Contact, Maximum Voltage Rating: 600V, Insulation Resistance (MOhm): 1000, Maximum Contact Resistance (mOhm): 10, Minimum Operating Temperature (°C): -40, Maximum Operating Temperature (°C): 105, Mating Cycle (Cycles): 30, Wire Size (AWG): 18-30, Housing Color: Black, Packaging: Tray, Product Weight (g): 1.225, Product Length (mm): 16.15, Product Depth (mm): 8.77, Product Height (mm): 9.91, Tradename: Micro-Fit 3.0™, Contact Material: Brass, Contact Plating: Tin Over Nickel, Mounting: Through Hole, Connector Type: Header, Contact Type: Male Pin, Mounting Type: Through Hole, Number Of Positions: 8, Number Of Rows: 2, Pitch: 0.118(3.00mm), Row Spacing: 0.118(3.00mm), Вес, г: 2.6, Бренд: Molex
