Brand: Marathon Item: Motor IP Rating: IP22 Mounting: Resilient base with extended studs Manufacturer Part Number: 056B17D5331 Voltage Rating: 115/208-230 VAC Horsepower Rating: 2hp Shaft Type: Round full flat with keyway Enclosure Type: ODP Voltage Type: AC Number of Phases: 1 Frame Material: Rolled steel Nameplate RPM: 1725rpm Motor Frame: NEMA 56H Motor Type: Induction Integrated Brake: No Shaft Diameter: 5/8in Efficiency: 78.6 Overload Type: Automatic Efficiency Group: Standard efficiency Motor Application: Fan and blower Synchronous Speed: 1800rpm Shaft Material: 1144 Stressproof (C-223) steel Electrically Reversible: Yes Insulation Class: Class B Service Factor: 1.15 NEMA Design: Design N Junction Box Orientation: F1 Mounting Orientation: Horizontal Marathon standard efficiency AC induction motor, fan and blower, 2hp, 1-phase, 115/208-230 VAC, 1800rpm, ODP, NEMA 56H frame, rolled steel, resilient base with extended studs mount.
