Brand: Marathon Item: Motor IP Rating: IP22 Mounting: Rigid base Manufacturer Part Number: 056B17D11018 Voltage Rating: 115/230 VAC, suitable for 208 VAC at 60 Hz Horsepower Rating: 1/2hp Shaft Type: Round with square key Enclosure Type: ODP Voltage Type: AC Number of Phases: 1 Frame Material: Rolled steel Nameplate RPM: 1725rpm Motor Frame: NEMA 56 Motor Type: Induction Integrated Brake: No Shaft Diameter: 5/8in Efficiency: 76.2 Overload Type: None Efficiency Group: Standard efficiency Motor Application: General purpose Synchronous Speed: 1800rpm Shaft Material: 1144 Stressproof (C-223) steel Electrically Reversible: Yes Insulation Class: Class B Service Factor: 1.25 NEMA Design: Design N Junction Box Orientation: F1 Mounting Orientation: Horizontal Marathon standard efficiency AC induction motor, general purpose, 1/2hp, 1-phase, 115/230 VAC, suitable for 208 VAC at 60 Hz, 1800rpm, ODP, NEMA 56 frame, rolled steel, rigid base mount.
