Brand: Contrinex Item: Proximity sensor Connection: Pigtail IP Rating: IP68 Operating Temperature: -25 to 70c Port Protocol(s): IO-Link Class A Device Housing Material: 304 stainless steel Housing Size: 10mm diameter x 35mm body Operating Voltage: 10-30 VDC Cable Length: 5.5in/140mm Shape: Tubular Communication Port and Connection Type(s): (1) 3-wire pigtail (IO-Link) port(s) Port Speed(s): IO-Link COM2 IO-Link Version: IO-Link v1.0 Standard I/O Mode Supported: Yes Jacket Material: 316L stainless steel Operation Mode: N.O. Application: Maritime and IO-Link Conductor Size: 26 AWG Sensor Type: Inductive Sensing Method: Standard sensing Number of Wires: 3 Switching Output: PNP Sensing Distance: 0.6mm Switching Frequency: 2000 Hz IO-Link Compatible: Yes Barrel Type: Threaded Adjustable: No Mounting Type: Flush Weld Field Immune: No Chip Immune: No Contrinex inductive proximity sensor, tubular, 10mm diameter x 35mm body, 304 stainless steel housing, PNP, N.O., 0.6mm sensing distance, flush, 2000 Hz switching frequency, IP68, pigtail.
