Brand: Marathon Item: Motor IP Rating: IP43 Series: Black MAX Mounting: C-face/rigid base Manufacturer Part Number: 215THTL7726 Voltage Rating: 230/460 VAC Horsepower Rating: 10hp Shaft Type: Round with square key Enclosure Type: TENV Voltage Type: AC Number of Phases: 3 Frame Material: Cast aluminum Nameplate RPM: 1774rpm Motor Frame: NEMA 215TC Motor Type: Induction Integrated Brake: No Shaft Diameter: 1-3/8in Efficiency: 90.2 Overload Type: None Efficiency Group: High efficiency Motor Application: High-performance inverter duty Synchronous Speed: 1800rpm Shaft Material: 1045 hot rolled (C-204) steel Electrically Reversible: Yes Insulation Class: Class F Service Factor: 1.0 NEMA Design: Design A Junction Box Orientation: F1 reversible Mounting Orientation: Horizontal or vertical Constant Torque Rating: 1000:1 Variable Torque Rating: 10:1 Marathon Black MAX high efficiency AC induction motor, high-performance inverter duty, 10hp, 3-phase, 230/460 VAC, 1800rpm, TENV, NEMA 215TC frame, cast aluminum, C-face/rigid base mount.
