Brand: Contrinex Item: Proximity sensor Connection: Pigtail IP Rating: IP68 Operating Temperature: -25 to 70c Port Protocol(s): IO-Link Class A Device Housing Material: 304 stainless steel Housing Size: 8mm diameter x 30mm body Operating Voltage: 10-30 VDC Cable Length: 6.5ft/2m Shape: Tubular Communication Port and Connection Type(s): (1) 3-wire pigtail (IO-Link) port(s) Port Speed(s): IO-Link COM2 IO-Link Version: IO-Link v1.1 Standard I/O Mode Supported: Yes Jacket Material: 316L stainless steel Operation Mode: N.O. Application: High pressure hydraulic and IO-Link Conductor Size: 26 AWG Sensor Type: Inductive Sensing Method: Standard sensing Number of Wires: 3 Switching Output: PNP Sensing Distance: 1.5mm Switching Frequency: 800 Hz IO-Link Compatible: Yes Barrel Type: Threaded Adjustable: No Mounting Type: Flush Weld Field Immune: No Chip Immune: No Operating Pressure: 7252psi (500 bar) Contrinex inductive proximity sensor, tubular, 8mm diameter x 30mm body, 304 stainless steel housing, PNP, N.O., 1.5mm sensing distance, flush, 800 Hz switching frequency, IP68, pigtail.
