Brand: Marathon Item: Motor IP Rating: IP54 Series: Symax Mounting: C-face/rigid base Manufacturer Part Number: 056PNRA10102 Requires: Drive Voltage Rating: 230/460 VAC Horsepower Rating: 1-1/2hp Shaft Type: Round with square key Enclosure Type: TENV Voltage Type: AC Number of Phases: 3 Frame Material: Rolled steel Nameplate RPM: 1800rpm Motor Frame: NEMA S56C Motor Type: Permanent magnet Integrated Brake: No Shaft Diameter: 5/8in Efficiency: 86 Overload Type: None Efficiency Group: Premium efficiency Motor Application: High-performance inverter duty Synchronous Speed: 1800rpm Shaft Material: 1144 Stressproof (C-223) steel Electrically Reversible: Yes Insulation Class: Class F Service Factor: 1.0 Junction Box Orientation: F1 Mounting Orientation: Horizontal Constant Torque Rating: 20:1 Variable Torque Rating: 20:1 Marathon Symax premium efficiency AC permanent magnet motor, high-performance inverter duty, 1-1/2hp, 3-phase, 230/460 VAC, 1800rpm, TENV, NEMA S56C frame, rolled steel, C-face/rigid base mount. Requires drive.
